——————————————————————————————————— Hairui fit-up assembling rotator are known worldwide for their excellent quality.
According to different diameter range of the workpiece, there are fixed center distance model and adjustable center distance model for choose.
HRPZ-fit-up assembling rotator is mainly used for paired assembly between the cylinders and between the cylinder and the head, and it is divided into two models: steel roller model and long shaft roller model. The steel roller type adopts the structure of eighteen steel rollers in a row, and the six drive steel rollers are connected by couplings, the long shaft roller type adopts the structure of three long shaft rollers in a row, and the two drive long shaft rollers are connected by a coupling, and equipped with auxiliary rollers to support the drive long shaft roller to avoid bending deformation caused by long-term use. Both models use the drive roller to drive the cylinder to rotate to adjust the relative position between the cylinders, which are only suitable for light cylinders. The standard model is fixed center distance model, if the diameter of the cylinder exceeds the diameter range of the standard model, adjustable center distance model can be selected. The electrical control system adopts frequency conversion speed regulation and cordless remote controller control, the equipment has the advantages of advanced structure, stable and reliable operation, high degree of automation, convenient operation and so on.
Be Your Strong Partner
China's First-class FRP Oil Tank Equipment Manufacturer
Provide Complete FRP Oil Tank Production Process Training
|
Model |
HRPZ-10(S) |
HRPZ-10(L) |
|
Structure Type |
Steel Roller Type |
Long Shaft Roller Type |
|
Max Load |
10000kg |
|
|
Roller Center Distance Adjustment Mode |
Fixed, Optional Bolt Adjustable or Screw Adjustable (Need Add Integral Base) |
|
|
Cylinder Diameter |
Fixed Center Distance Model: 2000-3200mm Adjustable Center Distance Model: 500-3200mm |
|
|
Drive Roller Diameter & Width |
Ø180×120mm |
Ø180×3000mm |
|
Drive Roller Quantity |
6×2 |
2×2 |
|
Driven Roller Diameter & Width |
Ø180×80mm |
Ø180×2000mm |
|
Driven Roller Quantity |
12×2 |
1×2 |
|
Auxiliary Supporting Roller Quantity |
None |
4 |
|
Roller Speed |
200-2000mm/min |
|
|
Motor Power |
2×1.1kw |
|
|
Adjust Mode of Speed |
Inverter Control |
|
|
IP Grade |
IP54 |
|
|
Input Power Supply |
3×380/400/415V, 50/60Hz |
|
|
Equipment Main Color |
RAL 5015 Himmelblau or Customized |
|
According to the actual needs of customers, provide corresponding technical guidance and equipment information, answer various questions raised by customers, design laser processing solutions for customers from technical feasibility, and provide related equipment for customers to visit, sample, test machine.
Sales Service
Investigate the customer’s machine use site, assist the user in planning the layout of the water, electricity, gas and other equipment in the production site according to the actual situation on site, provide the customer with a complete set of equipment operation instructions, and provide training service for the user’s equipment operator. Before delivery, train the user's equipment operators on basic equipment theory, safety protection and equipment maintenance.
After Sales Service
In the user’s factory, the user’s equipment operator is trained in actual processing operations, equipment daily maintenance and safe operation to ensure that the user can familiarize with the equipment operation rules and methods as soon as possible, and can independently use the equipment for production. After the complete set of equipment is installed and debugged at the user’s site, the warranty is free for one year from the date of acceptance by the user. Our company will also arrange technical personnel to conduct technical visits from time to time, communicate with customers on routine maintenance and inspection of equipment, and answer various questions raised by users.
Service Commitment
Service response time within 2 hours, the professional after-sales service team provides 24-hour technical support by email, video, telephone and other communication methods to provide customers with timely, comprehensive, convenient and efficient technical services.
